nGen_FLEX was developed with Eastman chemical company. Based on their work with co-polyesters nGen_FLEX makes a very compatible materials with other Amphora grade materials. This means you can expect to mix both materials with good adhesion properties to truly form a dual extruded model.
With just the right amount of flex, nGen_FLEX is best described as a semi flexible materials. Still capable of being fed through a Bowden tube and printed at regular PLA speeds.
nGen_FLEX is engineered as a semi-flexible materials which allows most users to print at regular print speeds, cutting down build times compared to other very flexible filaments. Also bowden style 3D printers, 1.75mm and 2.85mm, will be able to push this filament through without much trouble.
nGen_FLEX is temperature resistant to about 125C. That means 3D printed objects can be steam sterilized at 121C.
Flexible and tough
nGen_FLEX is best described as a semi-flexible material with good printability on most 3D printers eliminating the use for specialized flex extruders. By adjusting infill and perimeter settings it’s possible to influence how flexible a part should feel after printing. Printed in single perimeters and without infill or very little objects will feel quite flexible, but printed with multiple perimeters and more infill objects will be very firm and tough. The material is rated at a shore hardness of 95A.
More info on: http://ngen-flex.colorfabb.com/
All colorFabb 3d printing filaments are produced in our own production facility, situated in the Netherlands. Since no external parties are involved in the making of colorFabb filament we can ensure consistent quality on every order.
Excellent diameter tolerance
An important machine in our production are the laser measurement systems used to check the diameter of our filament real time during production. It’s measured over 1000 times per second and helps us guarantee that each spool of colorFabb 3d printing filament produced within tolerance. We can guarantee 0,05mm +/- on both 2,85mm and 1,75mm colorFabb 3d printing filament, which means you can rest assured that your printer is extruding the exact amount of material.
Within minutes of production a spool of colorFabb 3d printing filament is sealed airtight with a double barrier foil. To go the extra mile, we’ll also seal the fancy cardboard box that we use to ship our product. You can make sure colorFabb 3d printing filament is fresh and ready for 3d printing when you’re done unboxing.
The colorFabb testlab features a wide range of popular 3d printers. We’re continuously testing on our 3d printers to keep checking the quality of the materials we produce and to develop exciting new materials for the maker community. If your not sure how to print with our materials on your 3d printer, please contact firstname.lastname@example.org
ColorFabb was founded as a brand of Helian Polymers, a sister company of Peter Holland which have been active in the master batch and additives for the plastics processing industry. Our knowhow, network and partnerships is driving material innovations and quality. You can expect colorFabb to keep on developing interesting new materials, which will be tested on a variety of printers to make sure it’ll get the job done.
NET WEIGHT: 0.65 KG (1.43 LB)
|240°C - 260°C
Adviced 3d print speed: 40 - 60 mm/s
Advised Heated bed: 80C+
nGen_FLEX gives best results on a buildTak covered buildplate, heated at around 80C. Make sure the distance between nozzle and buildplate is not too close, first layer should not be squeezed too much.
- More information on printing nGen_FLEX material can be found: ngen-flex.colorFabb.com/how
